AV Line M4250-9G1F-PoE+ (GSM4210PD)
24x1G PoE+ 300W 2x1G and 4xSFP Managed Switch
Öne Çıkan Özellikler
- 24-port 10/100/1000BASE-T (RJ45) PoE+ with 300W PoE budget
- 2-port 10/100/1000BASE-T (RJ45)
- 4-port 1000BASE-X (SFP)
- 60 Gbps non-blocking fabric across 30 ports
- Out-of-band 1G Ethernet management port
- USB-C and RJ45 RS232 console ports and USB-A storage port
- Front black display panel and all ports in the back
- Possible reversed mounting with ports in the front
- Rack-mounting standard brackets
- Longer brackets for recessed mounting (2 inches / 5 cm)
- Threaded hole in front (1xM10) for clamps
- Threaded holes on the bottom (4xM5) for 50x100mm VESA plates
- Selectable fan modes for fanless, quiet, or cool operation
- Ürün Tanımı
- Teknik Özellikler
Switching engineered for 1G AV over IP with versatile mounting options for under a table or behind a display. Pre-configured for out of the box functionality!
Groundbreaking AV GUI
A simplified user interface makes it easy to assign configuration profiles to each port.
Multicast in an Instant
NETGEAR IGMP Plus™ provides multicast functionality right out of the box for most AV over IP applications.
Sleek, Quiet Design
Less fan noise, and mounting ears included for under-table or wall mounting.
Automatic ConfigurationAuto-trunk and auto-LAG functionality auto connects with other M4250 (and M4300) switches.
FAST, EASY CONFIGURATION FOR AV PROS
A streamlined interface enables factory default AV settings or user-specified AV profiles to be assigned to individual ports with just a few clicks.
FOCUS ON THE EVENT NOT FAN NOISE
Most models have quiet mode which greatly reduces fan noise, and some models are even fanless.
DESIGNED FOR AV OVER IP RIGHT OUT OF THE BOX
With built-in NETGEAR IGMP Plus™, there's little-to-no setup required for flawless Video over IP delivery. Enable multicasting right out of the box.
MAXIMIZE PERFORMANCE WITH NETGEAR ACCESS POINTS
Enable powerful, reliable WiFi at your location with WAX600 Series PoE access points.
| Primary Port Speed | 1 Gigabit |
| Number of Ports | 10 (8x 1G PoE+, 2x SFP+) |
| PoE Ports / Budget | 8 PoE+ (30W/port), 110W Budget |
| IGMP Support | Enhanced (NETGEAR IGMP Plus™) |
| Jumbo Frame Support | Yes, up to 12kb |
| AVB Support | Yes. Electronic license required, activation key sent via email (AVB4210PX-10000S) |
| Acoustics | Fanless |
| Power Consumption | With PoE: 132.25W/451.5Btu/hr Without PoE : 9.88W/33.73Btu/hr Standby without any port connection: 6.4W/22.02Btu/hr |
Dimensions (WxDxH)
- 210x 140 x 40 mm
Weight
- 965g (2.13lb)
